Central heating boiler Centrometal EKO-CK P 25

Boiler for central heating Centrometal EKO-CK P 25

Centrometal EKO-CK P boilers with a rated thermal output of 14 to 110 kW are intended for burning with solid fuel, pellets, oil or gas. They are intended for heating from the smallest to large objects, either as a basic source of heat or, which is increasingly common today, as an alternative source. They are recognizable by the successful combination of modern technologies and quality building materials with ease of installation and use.

A series of proven technical solutions make these boilers safe and reliable in operation. The possibility of simple installation of pellet, oil or gas equipment is a special value of these boilers. Made in accordance with the European standard EN 303-5

Basic characteristics of Centrometal EKO-CK P boilers:

• Hot water boiler for central heating intended for burning with several types of fuel (solid, pellet, liquid or gas), nominal heat output from 14 to 110 kW.
• Appropriately dimensioned combustion chamber and the routing of combustion gases in three passages ensure a high degree of utilization of the boiler, which makes it "economical".
• The boiler hearth is made of high-quality 5 mm boiler sheet.
• The large door and firebox of the boiler enable the burning of coarse solid fuel and easy cleaning and maintenance. Simple replacement of the opening direction of the upper and lower doors.
• Possibility of installation of thermal protection on openings prepared for this purpose.
• The boilers are factory-equipped with a thermostat that controls the operation of the pump.
• A separate body of the boiler is supplied, a separate formwork with thermal insulation, which enables easy transport and installation and reduces the risk of damage.
• The boiler's basic delivery includes a boiler water temperature indicator and accessories for cleaning and an ashtray.
• In the case of burning with oil or gas, a set for installing an oil/gas burner and turbulators is required (the number depends on the power of the boiler).
• For burning with wood pellets, the Cm Pellet-set contains a set for installing a pellet burner on the lower boiler door, turbulators, pellet burner, pellet tank, pellet conveyor and boiler regulation.
• When firing with oil/gas or pellets, it is necessary to install turbulators in the boiler (factory delivery with Cm Pellet-set, to be ordered additionally for firing with oil/gas).
• The basic boiler regulation of the burner (oil/gas) is additionally supplied, and it is placed in the factory-prepared place on the upper cover of the boiler formwork.
• The boiler has been tested and certified according to European standards EN 303-5 and EN 304 and manufactured in accordance with ISO 9001 and ISO 14001.
