Wood-burning fireplace Xena Mini 7kW
Timeless design paired with a 160 ° glass opening that offers a perfect view of the flame from every perspective. Enjoy fiery, romantic moments through the generously designed panoramic window. The latest technology is hidden behind a timeless, elegant design. Under the fireplace there is a wood container with a separate door, which is perfectly integrated into the design.
The Thermia company is based on rich industrial experience in sheet metal processing and is rapidly conquering the most demanding markets in Europe in the fireplace and flue program sectors. With rapid development and superbly equipped facilities, it can boast the production of first-class fireplaces and stoves that easily pass certification tests according to European standards.
Thermia offers attractive products in terms of appearance and technical characteristics, designs or redesigns fireplaces according to the client's request, and offers high-volume production.
Technical characteristics:
- body of the fireplace: black steel
- Fireplace lining: black steel
- covering of the firebox: thermal concrete
- air regulation: manual
- window washing function: (secondary air supply)
- flue outlet: at the top
- flue connection: Ø 150 mm
- external air supply connection: Ø 100 mm
- height: 1143 mm
- width: 480 mm
- depth: 480 mm
- weight: 106 kg
- max. length of wood: 350 mm
- glass dimensions (HxW): 435x430 mm
- distance to flammable things (back / side / front): 200 mm/ 200 mm/ 800 mm
- nominal power: 7 kW
- efficiency: 80.43%
- combustion: 2.27 kg/h
- exhaust gas flow: 6.25 g/s
- exhaust gas temperature: 291 ° C
- underpressure: 12 Pa
- fine dust: 24 mg/Nm3
- the product meets the requirements of conformity: DIN EN 13240, BlmSchV: Yes, level 2
